dauxiliary.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Functions
int	d_check_orthogonality (int M, int N, int LDQ, double *Q)
int	d_check_QRfactorization (int M, int N, double *A1, double *A2, int LDA, double *Q)
int	d_check_LLTfactorization (int N, double *A1, double *A2, int LDA, int uplo)
double	d_check_gemm (PLASMA_enum transA, PLASMA_enum transB, int M, int N, int K, double alpha, double *A, int LDA, double *B, int LDB, double beta, double *Cplasma, double *Cref, int LDC, double *Cinitnorm, double *Cplasmanorm, double *Clapacknorm)
double	d_check_trsm (PLASMA_enum side, PLASMA_enum uplo, PLASMA_enum trans, PLASMA_enum diag, int M, int NRHS, double alpha, double *A, int LDA, double *Bplasma, double *Bref, int LDB, double *Binitnorm, double *Bplasmanorm, double *Blapacknorm)
double	d_check_solution (int M, int N, int NRHS, double *A1, int LDA, double *B1, double *B2, int LDB, double *anorm, double *bnorm, double *xnorm)

---

Function Documentation

double d_check_gemm	(	PLASMA_enum	transA,
		PLASMA_enum	transB,
		int	M,
		int	N,
		int	K,
		double	alpha,
		double *	A,
		int	LDA,
		double *	B,
		int	LDB,
		double	beta,
		double *	Cplasma,
		double *	Cref,
		int	LDC,
		double *	Cinitnorm,
		double *	Cplasmanorm,
		double *	Clapacknorm
	)

Definition at line 210 of file dauxiliary.c.

References cblas_daxpy(), cblas_dgemm(), CblasColMajor, and max.

{
    double beta_const = -1.0;
    double Rnorm;
    double *work = (double *)malloc(max(K,max(M, N))* sizeof(double));

    *Cinitnorm   = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', M, N, Cref,    LDC, work);
    *Cplasmanorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', M, N, Cplasma, LDC, work);

    cblas_dgemm(CblasColMajor, (CBLAS_TRANSPOSE)transA, (CBLAS_TRANSPOSE)transB, M, N, K,
                (alpha), A, LDA, B, LDB, (beta), Cref, LDC);

    *Clapacknorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', M, N, Cref, LDC, work);

    cblas_daxpy(LDC * N, (beta_const), Cplasma, 1, Cref, 1);

    Rnorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', M, N, Cref, LDC, work);

    free(work);

    return Rnorm;
}

Here is the call graph for this function:

int d_check_LLTfactorization	(	int	N,
		double *	A1,
		double *	A2,
		int	LDA,
		int	uplo
	)

Definition at line 147 of file dauxiliary.c.

References cblas_dtrmm(), CblasColMajor, CblasLeft, CblasLower, CblasNonUnit, CblasRight, CblasTrans, CblasUpper, and PlasmaUpper.

{
    double Anorm, Rnorm;
    double alpha;
    int info_factorization;
    int i,j;
    double eps;

    eps = LAPACKE_dlamch_work('e');

    double *Residual = (double *)malloc(N*N*sizeof(double));
    double *L1       = (double *)malloc(N*N*sizeof(double));
    double *L2       = (double *)malloc(N*N*sizeof(double));
    double *work              = (double *)malloc(N*sizeof(double));

    memset((void*)L1, 0, N*N*sizeof(double));
    memset((void*)L2, 0, N*N*sizeof(double));

    alpha= 1.0;

    LAPACKE_dlacpy_work(LAPACK_COL_MAJOR,' ', N, N, A1, LDA, Residual, N);

    /* Dealing with L'L or U'U  */
    if (uplo == PlasmaUpper){
        LAPACKE_dlacpy_work(LAPACK_COL_MAJOR,'u', N, N, A2, LDA, L1, N);
        LAPACKE_dlacpy_work(LAPACK_COL_MAJOR,'u', N, N, A2, LDA, L2, N);
        cblas_dtrmm(CblasColMajor, CblasLeft, CblasUpper, CblasTrans, CblasNonUnit, N, N, (alpha), L1, N, L2, N);
    }
    else{
        LAPACKE_dlacpy_work(LAPACK_COL_MAJOR,'l', N, N, A2, LDA, L1, N);
        LAPACKE_dlacpy_work(LAPACK_COL_MAJOR,'l', N, N, A2, LDA, L2, N);
        cblas_dtrmm(CblasColMajor, CblasRight, CblasLower, CblasTrans, CblasNonUnit, N, N, (alpha), L1, N, L2, N);
    }

    /* Compute the Residual || A -L'L|| */
    for (i = 0; i < N; i++)
        for (j = 0; j < N; j++)
           Residual[j*N+i] = L2[j*N+i] - Residual[j*N+i];

    Rnorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', N, N, Residual, N, work);
    Anorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', N, N, A1, LDA, work);

    printf("============\n");
    printf("Checking the Cholesky Factorization \n");
    printf("-- ||L'L-A||_oo/(||A||_oo.N.eps) = %e \n",Rnorm/(Anorm*N*eps));

    if ( isnan(Rnorm/(Anorm*N*eps)) || (Rnorm/(Anorm*N*eps) > 10.0) ){
        printf("-- Factorization is suspicious ! \n");
        info_factorization = 1;
    }
    else{
        printf("-- Factorization is CORRECT ! \n");
        info_factorization = 0;
    }

    free(Residual); free(L1); free(L2); free(work);

    return info_factorization;
}

Here is the call graph for this function:

int d_check_orthogonality	(	int	M,
		int	N,
		int	LDQ,
		double *	Q
	)

d Tue Nov 22 14:36:01 2011

Definition at line 20 of file dauxiliary.c.

References cblas_dsyrk(), CblasColMajor, CblasNoTrans, CblasTrans, CblasUpper, and min.

{
    double alpha, beta;
    double normQ;
    int info_ortho;
    int i;
    int minMN = min(M, N);
    double eps;
    double *work = (double *)malloc(minMN*sizeof(double));

    eps = LAPACKE_dlamch_work('e');
    alpha = 1.0;
    beta  = -1.0;

    /* Build the idendity matrix USE DLASET?*/
    double *Id = (double *) malloc(minMN*minMN*sizeof(double));
    memset((void*)Id, 0, minMN*minMN*sizeof(double));
    for (i = 0; i < minMN; i++)
        Id[i*minMN+i] = (double)1.0;

    /* Perform Id - Q'Q */
    if (M >= N)
        cblas_dsyrk(CblasColMajor, CblasUpper, CblasTrans, N, M, alpha, Q, LDQ, beta, Id, N);
    else
        cblas_dsyrk(CblasColMajor, CblasUpper, CblasNoTrans, M, N, alpha, Q, LDQ, beta, Id, M);

    normQ = LAPACKE_dlansy_work(LAPACK_COL_MAJOR, 'i', 'u', minMN, Id, minMN, work);

    printf("============\n");
    printf("Checking the orthogonality of Q \n");
    printf("||Id-Q'*Q||_oo / (N*eps) = %e \n",normQ/(minMN*eps));

    if ( isnan(normQ / (minMN * eps)) || (normQ / (minMN * eps) > 10.0) ) {
        printf("-- Orthogonality is suspicious ! \n");
        info_ortho=1;
    }
    else {
        printf("-- Orthogonality is CORRECT ! \n");
        info_ortho=0;
    }

    free(work); free(Id);

    return info_ortho;
}

Here is the call graph for this function:

int d_check_QRfactorization	(	int	M,
		int	N,
		double *	A1,
		double *	A2,
		int	LDA,
		double *	Q
	)

Definition at line 70 of file dauxiliary.c.

References cblas_dgemm(), CblasColMajor, CblasNoTrans, L, and max.

{
    double Anorm, Rnorm;
    double alpha, beta;
    int info_factorization;
    int i,j;
    double eps;

    eps = LAPACKE_dlamch_work('e');

    double *Ql       = (double *)malloc(M*N*sizeof(double));
    double *Residual = (double *)malloc(M*N*sizeof(double));
    double *work              = (double *)malloc(max(M,N)*sizeof(double));

    alpha=1.0;
    beta=0.0;

    if (M >= N) {
        /* Extract the R */
        double *R = (double *)malloc(N*N*sizeof(double));
        memset((void*)R, 0, N*N*sizeof(double));
        LAPACKE_dlacpy_work(LAPACK_COL_MAJOR,'u', M, N, A2, LDA, R, N);

        /* Perform Ql=Q*R */
        memset((void*)Ql, 0, M*N*sizeof(double));
        cblas_dgemm(CblasColMajor, CblasNoTrans, CblasNoTrans, M, N, N, (alpha), Q, LDA, R, N, (beta), Ql, M);
        free(R);
    }
    else {
        /* Extract the L */
        double *L = (double *)malloc(M*M*sizeof(double));
        memset((void*)L, 0, M*M*sizeof(double));
        LAPACKE_dlacpy_work(LAPACK_COL_MAJOR,'l', M, N, A2, LDA, L, M);

    /* Perform Ql=LQ */
        memset((void*)Ql, 0, M*N*sizeof(double));
        cblas_dgemm(CblasColMajor, CblasNoTrans, CblasNoTrans, M, N, M, (alpha), L, M, Q, LDA, (beta), Ql, M);
        free(L);
    }

    /* Compute the Residual */
    for (i = 0; i < M; i++)
        for (j = 0 ; j < N; j++)
            Residual[j*M+i] = A1[j*LDA+i]-Ql[j*M+i];

    Rnorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', M, N, Residual, M, work);
    Anorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', M, N, A2, LDA, work);

    if (M >= N) {
        printf("============\n");
        printf("Checking the QR Factorization \n");
        printf("-- ||A-QR||_oo/(||A||_oo.N.eps) = %e \n",Rnorm/(Anorm*N*eps));
    }
    else {
        printf("============\n");
        printf("Checking the LQ Factorization \n");
        printf("-- ||A-LQ||_oo/(||A||_oo.N.eps) = %e \n",Rnorm/(Anorm*N*eps));
    }

    if (isnan(Rnorm / (Anorm * N *eps)) || (Rnorm / (Anorm * N * eps) > 10.0) ) {
        printf("-- Factorization is suspicious ! \n");
        info_factorization = 1;
    }
    else {
        printf("-- Factorization is CORRECT ! \n");
        info_factorization = 0;
    }

    free(work); free(Ql); free(Residual);

    return info_factorization;
}

Here is the call graph for this function:

double d_check_solution	(	int	M,
		int	N,
		int	NRHS,
		double *	A1,
		int	LDA,
		double *	B1,
		double *	B2,
		int	LDB,
		double *	anorm,
		double *	bnorm,
		double *	xnorm
	)

Definition at line 276 of file dauxiliary.c.

References cblas_dgemm(), CblasColMajor, CblasNoTrans, and max.

{
/*     int info_solution; */
    double Rnorm = -1.00;
    double zone  =  1.0;
    double mzone = -1.0;
    double *work = (double *)malloc(max(M, N)* sizeof(double));

    *anorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', M, N,    A, LDA, work);
    *xnorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', M, NRHS, X, LDB, work);
    *bnorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', N, NRHS, B, LDB, work);

    cblas_dgemm(CblasColMajor, CblasNoTrans, CblasNoTrans, M, NRHS, N, (zone), A, LDA, X, LDB, (mzone), B, LDB);

    Rnorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', N, NRHS, B, M, work);

    free(work);

    return Rnorm;
}

Here is the call graph for this function:

double d_check_trsm	(	PLASMA_enum	side,
		PLASMA_enum	uplo,
		PLASMA_enum	trans,
		PLASMA_enum	diag,
		int	M,
		int	NRHS,
		double	alpha,
		double *	A,
		int	LDA,
		double *	Bplasma,
		double *	Bref,
		int	LDB,
		double *	Binitnorm,
		double *	Bplasmanorm,
		double *	Blapacknorm
	)

Definition at line 241 of file dauxiliary.c.

References cblas_daxpy(), cblas_dtrsm(), CblasColMajor, and max.

{
    double beta_const = -1.0;
    double Rnorm;
    double *work = (double *)malloc(max(M, NRHS)* sizeof(double));
    /*double eps = LAPACKE_dlamch_work('e');*/

    *Binitnorm   = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'i', M, NRHS, Bref,    LDB, work);
    *Bplasmanorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'm', M, NRHS, Bplasma, LDB, work);

    cblas_dtrsm(CblasColMajor, (CBLAS_SIDE)side, (CBLAS_UPLO)uplo,
                (CBLAS_TRANSPOSE)trans, (CBLAS_DIAG)diag, M, NRHS,
                (alpha), A, LDA, Bref, LDB);

    *Blapacknorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'm', M, NRHS, Bref, LDB, work);

    cblas_daxpy(LDB * NRHS, (beta_const), Bplasma, 1, Bref, 1);

    Rnorm = LAPACKE_dlange_work(LAPACK_COL_MAJOR, 'm', M, NRHS, Bref, LDB, work);
    Rnorm = Rnorm / *Blapacknorm;
    /* max(M,NRHS) * eps);*/

    free(work);

    return Rnorm;
}

Here is the call graph for this function:
