This graph shows which files directly or indirectly include this file:

Data Structures
struct	pme_amd64_umask_t

struct	pme_amd64_entry_t

Macros
#define	PMU_AMD64_NUM_PERFSEL 8 /* number of PMCs defined */

#define	PMU_AMD64_NUM_PERFCTR 16 /* number of PMDs defined */

#define	PMU_AMD64_NUM_COUNTERS 4 /* number of EvtSel/EvtCtr */

#define	PMU_AMD64_NUM_COUNTERS_F15H 6 /* number of EvtSel/EvtCtr */

#define	PMU_AMD64_COUNTER_WIDTH 48 /* hw counter bit width */

#define	PMU_AMD64_CNT_MASK_MAX 4 /* max cnt_mask value */

#define	PMU_AMD64_IBSFETCHCTL_PMC 6 /* IBS: fetch PMC base */

#define	PMU_AMD64_IBSFETCHCTL_PMD 6 /* IBS: fetch PMD base */

#define	PMU_AMD64_IBSOPCTL_PMC 7 /* IBS: op PMC base */

#define	PMU_AMD64_IBSOPCTL_PMD 9 /* IBS: op PMD base */

#define	PFMLIB_AMD64_MAX_UMASK 13

#define	PFMLIB_AMD64_UMASK_COMBO 0x1 /* unit mask can be combined */

#define	PFMLIB_AMD64_FROM_REV(rev) ((rev)<<8)

#define	PFMLIB_AMD64_TILL_REV(rev) ((rev)<<16)

#define	PFMLIB_AMD64_NOT_SUPP 0x1ff00

#define	PFMLIB_AMD64_TILL_K8_REV_C PFMLIB_AMD64_TILL_REV(AMD64_K8_REV_C)

#define	PFMLIB_AMD64_K8_REV_D PFMLIB_AMD64_FROM_REV(AMD64_K8_REV_D)

#define	PFMLIB_AMD64_K8_REV_E PFMLIB_AMD64_FROM_REV(AMD64_K8_REV_E)

#define	PFMLIB_AMD64_TILL_K8_REV_E PFMLIB_AMD64_TILL_REV(AMD64_K8_REV_E)

#define	PFMLIB_AMD64_K8_REV_F PFMLIB_AMD64_FROM_REV(AMD64_K8_REV_F)

#define	PFMLIB_AMD64_TILL_FAM10H_REV_B PFMLIB_AMD64_TILL_REV(AMD64_FAM10H_REV_B)

#define	PFMLIB_AMD64_FAM10H_REV_C PFMLIB_AMD64_FROM_REV(AMD64_FAM10H_REV_C)

#define	PFMLIB_AMD64_TILL_FAM10H_REV_C PFMLIB_AMD64_TILL_REV(AMD64_FAM10H_REV_C)

#define	PFMLIB_AMD64_FAM10H_REV_D PFMLIB_AMD64_FROM_REV(AMD64_FAM10H_REV_D)

Enumerations
enum	amd64_rev_t { AMD64_CPU_UN , AMD64_K7 , AMD64_K8_REV_B , AMD64_K8_REV_C , AMD64_K8_REV_D , AMD64_K8_REV_E , AMD64_K8_REV_F , AMD64_K8_REV_G , AMD64_FAM10H_REV_B , AMD64_FAM10H_REV_C , AMD64_FAM10H_REV_D , AMD64_FAM10H_REV_E , AMD64_FAM15H_REV_B }

Functions
static int	from_revision (unsigned int flags)

static int	till_revision (unsigned int flags)

Variables
static const char *	amd64_rev_strs []

static const char *	amd64_cpu_strs []

Macro Definition Documentation

◆ PFMLIB_AMD64_FAM10H_REV_C

#define PFMLIB_AMD64_FAM10H_REV_C PFMLIB_AMD64_FROM_REV(AMD64_FAM10H_REV_C)

Definition at line 123 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_FAM10H_REV_D

#define PFMLIB_AMD64_FAM10H_REV_D PFMLIB_AMD64_FROM_REV(AMD64_FAM10H_REV_D)

Definition at line 125 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_FROM_REV

#define PFMLIB_AMD64_FROM_REV ( rev ) ((rev)<<8)

Definition at line 114 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_K8_REV_D

#define PFMLIB_AMD64_K8_REV_D PFMLIB_AMD64_FROM_REV(AMD64_K8_REV_D)

Definition at line 118 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_K8_REV_E

#define PFMLIB_AMD64_K8_REV_E PFMLIB_AMD64_FROM_REV(AMD64_K8_REV_E)

Definition at line 119 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_K8_REV_F

#define PFMLIB_AMD64_K8_REV_F PFMLIB_AMD64_FROM_REV(AMD64_K8_REV_F)

Definition at line 121 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_MAX_UMASK

#define PFMLIB_AMD64_MAX_UMASK 13

Definition at line 50 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_NOT_SUPP

#define PFMLIB_AMD64_NOT_SUPP 0x1ff00

Definition at line 116 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_TILL_FAM10H_REV_B

#define PFMLIB_AMD64_TILL_FAM10H_REV_B PFMLIB_AMD64_TILL_REV(AMD64_FAM10H_REV_B)

Definition at line 122 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_TILL_FAM10H_REV_C

#define PFMLIB_AMD64_TILL_FAM10H_REV_C PFMLIB_AMD64_TILL_REV(AMD64_FAM10H_REV_C)

Definition at line 124 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_TILL_K8_REV_C

#define PFMLIB_AMD64_TILL_K8_REV_C PFMLIB_AMD64_TILL_REV(AMD64_K8_REV_C)

Definition at line 117 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_TILL_K8_REV_E

#define PFMLIB_AMD64_TILL_K8_REV_E PFMLIB_AMD64_TILL_REV(AMD64_K8_REV_E)

Definition at line 120 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_TILL_REV

#define PFMLIB_AMD64_TILL_REV ( rev ) ((rev)<<16)

Definition at line 115 of file pfmlib_amd64_priv.h.

◆ PFMLIB_AMD64_UMASK_COMBO

#define PFMLIB_AMD64_UMASK_COMBO 0x1 /* unit mask can be combined */

Definition at line 113 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_CNT_MASK_MAX

#define PMU_AMD64_CNT_MASK_MAX 4 /* max cnt_mask value */

Definition at line 44 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_COUNTER_WIDTH

#define PMU_AMD64_COUNTER_WIDTH 48 /* hw counter bit width */

Definition at line 43 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_IBSFETCHCTL_PMC

#define PMU_AMD64_IBSFETCHCTL_PMC 6 /* IBS: fetch PMC base */

Definition at line 45 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_IBSFETCHCTL_PMD

#define PMU_AMD64_IBSFETCHCTL_PMD 6 /* IBS: fetch PMD base */

Definition at line 46 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_IBSOPCTL_PMC

#define PMU_AMD64_IBSOPCTL_PMC 7 /* IBS: op PMC base */

Definition at line 47 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_IBSOPCTL_PMD

#define PMU_AMD64_IBSOPCTL_PMD 9 /* IBS: op PMD base */

Definition at line 48 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_NUM_COUNTERS

#define PMU_AMD64_NUM_COUNTERS 4 /* number of EvtSel/EvtCtr */

Definition at line 41 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_NUM_COUNTERS_F15H

#define PMU_AMD64_NUM_COUNTERS_F15H 6 /* number of EvtSel/EvtCtr */

Definition at line 42 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_NUM_PERFCTR

#define PMU_AMD64_NUM_PERFCTR 16 /* number of PMDs defined */

Definition at line 40 of file pfmlib_amd64_priv.h.

◆ PMU_AMD64_NUM_PERFSEL

#define PMU_AMD64_NUM_PERFSEL 8 /* number of PMCs defined */

Definition at line 39 of file pfmlib_amd64_priv.h.

Enumeration Type Documentation

◆ amd64_rev_t

enum amd64_rev_t

Enumerator
AMD64_CPU_UN
AMD64_K7
AMD64_K8_REV_B
AMD64_K8_REV_C
AMD64_K8_REV_D
AMD64_K8_REV_E
AMD64_K8_REV_F
AMD64_K8_REV_G
AMD64_FAM10H_REV_B
AMD64_FAM10H_REV_C
AMD64_FAM10H_REV_D
AMD64_FAM10H_REV_E
AMD64_FAM15H_REV_B

Definition at line 68 of file pfmlib_amd64_priv.h.

             {
    AMD64_CPU_UN,
    AMD64_K7,
    AMD64_K8_REV_B,
    AMD64_K8_REV_C,
    AMD64_K8_REV_D,
    AMD64_K8_REV_E,
    AMD64_K8_REV_F,
    AMD64_K8_REV_G,
    AMD64_FAM10H_REV_B,
    AMD64_FAM10H_REV_C,
    AMD64_FAM10H_REV_D,
    AMD64_FAM10H_REV_E,
    AMD64_FAM15H_REV_B,
} amd64_rev_t;

Function Documentation

◆ from_revision()

static int from_revision ( unsigned int flags )

inlinestatic

Definition at line 127 of file pfmlib_amd64_priv.h.

{
    return ((flags) >> 8) & 0xff;
}

Here is the caller graph for this function:

◆ till_revision()

static int till_revision ( unsigned int flags )
